392-011 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 11POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Material | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Number of Positions | Termination | Contact Type | Number of Rows | Read Out | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Min] | Operating Temperature [Max] | Color | Gender | Pitch | Pitch | Card Type | Number of Positions/Bay/Row | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder Wire Wrap | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder Wire Wrap | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Wire Wrap | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Wire Wrap | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | 4-40 Flush Mount Threaded Insert Top Opening | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 11 | Solder | Cantilever | 1 | Single | 0.25 Ám | 10 Áin | -40 C | 105 ░C | Black | Female | 0.1 " | 2.54 mm | Non Specified - Single Edge | 11 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm |
