857-088 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 88POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Contact Material | Mounting Type | Number of Positions/Bay/Row | Contact Finish | Color | Number of Positions | Pitch | Pitch | Read Out | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder Eyelet(s) | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Through Hole | 44 | Tin | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Right Angle Through Hole | 44 | Tin | Black | 88 | 3.96 mm | 0.156 in | Single | 2 | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Through Hole | 44 | Tin | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Through Hole | 44 | Gold | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Through Hole | 44 | Gold | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Right Angle Through Hole | 44 | Gold | Black | 88 | 3.96 mm | 0.156 in | Single | 2 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Through Hole | 44 | Gold | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | Flush Mount M3 Threaded Insert Top Opening | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Board Edge Straddle Mount | 44 | Gold | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 | 0.25 Ám | 10 Áin | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Solder | 4-40 Flush Mount Threaded Insert Top Opening | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Board Edge Straddle Mount | 44 | Gold | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 | 0.25 Ám | 10 Áin | Card Extender | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Wire Wrap | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 125 °C | -40 C | Female | Copper Alloy | Through Hole | 44 | Tin | Black | 88 | 3.96 mm | 0.156 in | Dual | 2 |
