ALCOSWITCH DIP EDSP Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

E STACK PIANO 8P G LONG TUBE PD OFF

Part	Length	Length	Body Material	Mechanical Life	Electrical Life	Mounting Type	Pitch	Pitch	Actuator Type	Current Rating (Amps)	Contact Finish	Circuit	Number of Positions	Actuator Level	Contact Material	Voltage Rating	Termination Style	Operating Temperature [Max]	Operating Temperature [Min]	Height Above Board	Height Above Board
TE Connectivity AMP Connectors EDSP08SGLFNTU04
TE Connectivity AMP Connectors EDSP10SGLNNTR04	0.996 in	25.3 mm	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	Right Angle Surface Mount	2.54 mm	0.1 "	Piano	25 mA	Gold	SPST	10	Raised	Copper Alloy	24 VDC	Gull Wing	85 °C	-20 ░C	5 mm	0.197 in
TE Connectivity AMP Connectors EDSP06SGRNNTU04	0.596 in	15.14 mm	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	Right Angle Surface Mount	2.54 mm	0.1 "	Piano	25 mA	Gold	SPST	6	Flush Recessed	Copper Alloy	24 VDC	Gull Wing	85 °C	-20 ░C	5 mm	0.197 in
TE Connectivity AMP Connectors EDSP02SGLFNTR04	0.196 in	4.98 mm	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	Right Angle Surface Mount	2.54 mm	0.1 "	Piano	25 mA	Gold	SPST	2	Raised	Copper Alloy	24 VDC	Gull Wing	85 °C	-20 ░C	5 mm	0.197 in
TE Connectivity AMP Connectors EDSP08SGRFNTR04
TE Connectivity AMP Connectors EDSP08SGRFNTR04
TE Connectivity AMP Connectors EDSP10SGRNSTU04	0.996 in	25.3 mm	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	Right Angle Surface Mount	2.54 mm	0.1 "	Piano	25 mA	Gold	SPST	10	Flush Recessed	Copper Alloy	24 VDC	Gull Wing	85 °C	-20 ░C	5 mm	0.197 in
TE Connectivity AMP Connectors EDSP04SGLNNTR04	0.396 "	10.06 mm	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	Right Angle Surface Mount	2.54 mm	0.1 "	Piano	25 mA	Gold	SPST	4	Raised	Copper Alloy	24 VDC	Gull Wing	85 °C	-20 ░C	5 mm	0.197 in
TE Connectivity AMP Connectors EDSP06SGLNNTU04						Right Angle Surface Mount	2.54 mm	0.1 "	Piano	25 mA	Gold	SPST	6	Raised	Copper Alloy	24 VDC	Gull Wing	85 °C	-20 ░C	5 mm	0.197 in
TE Connectivity AMP Connectors EDSP06SGLNNTR04	0.596 in	15.14 mm	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	Right Angle Surface Mount	2.54 mm	0.1 "	Piano	25 mA	Gold	SPST	6	Raised	Copper Alloy	24 VDC	Gull Wing	85 °C	-20 ░C	5 mm	0.197 in
