POE576U Series
Manufacturer: Phihong USA
Beta
⌘K
POE INJECTOR 30W RACK
| Part | Input Connector | Weight | Weight | Output Connector | Note | Features | Mounting Type | Number of Ports | Voltage - Input [Max] | Voltage - Input [Min] | Compliance | Efficiency | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [z] | Data Rate | Operating Temperature [Max] | Operating Temperature [Min] | Approval Agency | Type | Power (Watts) - Per Port |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phihong USA | IEC 320-C14 | 8.5 lbs | 3.9 kg | RJ45 (Data Power) | AC Power Cord Sold Separately | OCP OTP OVP SCP | Rack Mount | 16 | 264 VAC | 90 VAC | IEEE802.3at | 75 % | 437 mm | 17.2 in | 9.06 " | 230 mm | 44 mm | 1.73 " | 10 Mbps 100 Mbps 1000 Mbps | 40 °C | 0 °C | CE cULus | Midspan Injector | 30 W |
 Phihong USA | IEC 320-C14 | 8.5 lbs | 3.9 kg | RJ45 (Data Power) | AC Power Cord Sold Separately | OCP OTP OVP SCP | Rack Mount | 8 | 264 VAC | 90 VAC | IEEE802.3at | 75 % | 437 mm | 17.2 in | 9.06 " | 230 mm | 44 mm | 1.73 " | 10 Mbps 100 Mbps 1000 Mbps | 40 °C | 0 °C | CE cULus | Midspan Injector | 30 W |
 Phihong USA | IEC 320-C14 | 8.5 lbs | 3.9 kg | RJ45 (Data Power) | AC Power Cord Sold Separately | OCP OTP OVP SCP | Rack Mount | 16 | 264 VAC | 90 VAC | IEEE802.3at | 75 % | 437 mm | 17.2 in | 9.06 " | 230 mm | 44 mm | 1.73 " | 10 Mbps 100 Mbps 1000 Mbps | 40 °C | 0 °C | CE cULus | Midspan Injector | 30 W |
 Phihong USA | IEC 320-C14 | 8.5 lbs | 3.9 kg | RJ45 (Data Power) | AC Power Cord Sold Separately | OCP OTP OVP SCP | Rack Mount | 8 | 264 VAC | 90 VAC | IEEE802.3at | 75 % | 437 mm | 17.2 in | 9.06 " | 230 mm | 44 mm | 1.73 " | 10 Mbps 100 Mbps 1000 Mbps | 40 °C | 0 °C | CE cULus | Midspan Injector | 30 W |
