306-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 46POS 0.156
| Part | Material - Insulation | Termination Rows | Termination | Contact Type | Contact Finish | Read Out | Number of Positions | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Color | Number of Rows [custom] | Card Type | Flange Feature | Features | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Mounting Type | Contact Material | Gender | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Tin | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Tin | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Gold | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Gold | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Tin | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Gold | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder Eyelet(s) | Cantilever | Gold | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | -40 C | 105 ░C | 23 | Panel Mount | Copper Alloy | Female | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder Eyelet(s) | Cantilever | Tin | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | Flush Mount Side Opening Unthreaded | -40 C | 105 ░C | 23 | Panel Mount | Copper Alloy | Female | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Gold | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Solder | Cantilever | Tin | Dual | 46 | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | 2 | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | -40 C | 105 ░C | 23 | Panel Mount Through Hole | Copper Alloy | Female |
