629W2W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 2POS R/A SLDR
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Contact Material | Color | Contact Finish | Number of Positions | Mounting Type | Connector Type | Current Rating (Amps) | Ingress Protection | Material Flammability Rating | Shell Size, Connector Layout | Number of Rows | Connector Style | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Features | Termination | Flange Feature | Shell Material, Finish | Flange Feature | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Female Sockets and Male Pins | 10 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.38 µm | 15 µin | Board Lock Filter Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Male Pins | 30 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.38 µm | 15 µin | Grounding Indents Shielded | Solder | Housing/Shell | Nickel Plated Steel | 4-40 | |
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Female Sockets and Male Pins | 10 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.76 Ám | 30 Áin | Board Lock Filter Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Male Pins | 30 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.38 µm | 15 µin | Board Lock Filter Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Male Pins | 40 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.38 µm | 15 µin | Grounding Indents Shielded | Solder | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Female Sockets and Male Pins | 40 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.76 Ám | 30 Áin | Board Lock Filter Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Male Pins | 20 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.38 µm | 15 µin | Board Lock Filter Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell (M3) | Nickel Plated Steel | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Female Sockets and Male Pins | 40 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell | Nickel Plated Steel | 4-40 | Flash | ||
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Male Pins | 40 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.127 µm | 5 µin | Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell | Nickel Plated Steel | 4-40 | |
 EDAC Inc. | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Gold | 2 | Panel Mount Right Angle Through Hole | Plug Male Pins | 30 A | IP67 - Dust Tight Waterproof | UL94 V-0 | 1 (DE E) 2V2 2W2 2W2C 2WK2 | 1 | Combo D-Sub | Power | 0.38 µm | 15 µin | Board Lock Grounding Indents Mounting Brackets Shielded | Solder | Housing/Shell | Nickel Plated Steel | 4-40 |
