EVM080W Series

Catalog

LED DRIVER CC AC/DC 120-277V 175

Part	Mounting Type	Efficiency	Approval Agency	Operating Temperature	Type	Voltage - Output [Min]	Voltage - Output [Max]	Ratings	Topology	Termination Style	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Features	Voltage - Input (Min) [Min]	Number of Outputs	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Dimming	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)
ERP Power, LLC EVM080W-1750-42-Z1B	Chassis Mount	87 %	CB CCC CE CSA cURus KC	194 °F	Constant Current	30 V	42 V	IP20	AC DC Converter	Wire Leads	2.76 "	1.57 "	5.67 "	70 mm	40 mm	144 mm	OCP OTP SCP	120 VAC	1	277 VAC	1.75 A	Analog ELV TRIAC
ERP Power, LLC EVM080W-1900-42	Chassis Mount	89 %	CB CE cRUcs cUL FC UL		Constant Current	30 V	42 V	IP20 NEMA 410	AC DC Converter	Wire Leads	2.76 "	1.57 "	5.67 "	70 mm	40 mm	144 mm	OCP OTP SCP	120 VAC	1	277 VAC	1.9 A	ELV TRIAC	-30 ░C	90 °C	80 W
