BD9326EFJ Series
Manufacturer: Rohm Semiconductor
Beta
⌘K
DC-DC SWITCHING BUCK (STEP DOWN) REGULATOR, ADJUSTABLE, 4.75V-18VIN, 900MV-14.4VOUT, 3AOUT, HTSOP-8 ROHS COMPLIANT: YES
| Part | Number of Outputs | Package / Case | Package / Case [y] | Package / Case [x] | Voltage - Input (Min) [Min] | Supplier Device Package | Current - Output | Output Type | Synchronous Rectifier | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Function | Output Configuration | Voltage - Input (Max) [Max] | Frequency - Switching | Topology | Voltage - Output (Min/Fixed) | Voltage - Output (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 1 | 8-SOIC Exposed Pad | 3.9 mm | 0.154 in | 4.75 V | 8-HTSOP-J | 3 A | Adjustable | Surface Mount | 85 C | -40 ¯C | Step-Down | Positive | 18 V | 380 kHz | Buck | 0.9 V | 16.2 V |
