ED Series

Catalog

SOLID STATE RELAYS - SSRS SOLID STATE RELAY

Part	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Termination Style	Package / Case	Approval Agency	Load Current	Voltage - Input [Max]	Voltage - Input [Min]	Voltage - Load [Min]	Voltage - Load [Max]	Output Type	Termination Style
Sensata-Crydom ED10C10	80 °C	-30 ░C	Socketable	Plug In	Module	CE cURus IEC	10 A	32 VDC	18 VDC	1 V	100 V	DC
Sensata-Crydom ED06C5	80 °C	-30 ░C	Socketable	Plug In Quick Connect	Module	CE cURus IEC	5 A	32 VDC	18 VDC	1 V	48 V	DC	0.187 in 4.7 mm
Sensata-Crydom ED24E5	80 °C	-30 ░C	Socketable	Plug In Quick Connect	Module	CE cURus IEC	5 A	36 VAC	18 VAC/DC	24 V	280 V	AC Zero Cross	0.187 in 4.7 mm
Sensata-Crydom ED24C5R	80 °C	-30 ░C	Socketable	Plug In Quick Connect	Module	CE cURus IEC	5 A	32 VDC	18 VDC	24 V	280 V	AC	0.187 in 4.7 mm
