MOX HBC Hybrid Header, Right-Angle, Tin Plating, 64 Circuits
MOX HBC Hybrid Header, Right-Angle, Tin Plating, 64 Circuits
| Part | Contact Type | Insulation Height [custom] | Insulation Height [custom] | Contact Material | Contact Finish - Post | Contact Length - Post | Contact Length - Post | Current Rating (Amps) | Fastening Type | Insulation Color | Style | Insulation Material | Number of Positions | Voltage Rating | Number of Positions Loaded | Number of Rows [custom] | Mounting Type | Pitch - Mating | Pitch - Mating | Connector Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shrouding | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Contact Shape | Material Flammability Rating | Row Spacing - Mating | Row Spacing - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Male Pin | 0.591 in | 15 mm | Brass | Tin | 0.13 " | 3.3 mm | 5 A | Latch Lock | Black | Board to Cable/Wire | Polybutylene Terephthalate (PBT) | 64 | 13 V | All | 2 | Through Hole | 0.134 in | 3.4 mm | Header | 60 µin | 1.52 Ám | Shrouded - 4 Wall | Solder | -40 C | 105 ░C | Square | UL94 V-0 | 0.118 in | 3 mm |
 Molex |
