1971772 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN RCPT HSG 3POS 6.00MM
| Part | Color | Contact Type | Note | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Material | Mounting Type | Connector Type | Contact Termination | Number of Rows | Features | Fastening Type | Pitch [x] | Pitch [x] | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Purple | Tab | Contacts Not Included | 105 ░C | -55 °C | Polybutylene Terephthalate (PBT) Glass Filled | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | |
 TE Connectivity Raychem Cable Protection | Natural | Tab | Contacts Not Included | 105 ░C | -55 °C | Polybutylene Terephthalate (PBT) Glass Filled | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | |
TE Connectivity Raychem Cable Protection | Red | Tab | Contacts Not Included | 150 °C | -55 °C | Nylon Polyamide (PA) | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | |
 TE Connectivity Raychem Cable Protection | Black | Tab | Contacts Not Included | 150 °C | -55 °C | Nylon Polyamide (PA) | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | 4 |
 TE Connectivity Raychem Cable Protection | Red | Tab | Contacts Not Included | 150 °C | -55 °C | Nylon Polyamide (PA) | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | |
 TE Connectivity Raychem Cable Protection | Purple | Tab | Contacts Not Included | 105 ░C | -55 °C | Polybutylene Terephthalate (PBT) Glass Filled | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | 2 |
 TE Connectivity Raychem Cable Protection | Black | Tab | Contacts Not Included | 150 °C | -55 °C | Nylon Polyamide (PA) | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | 2 |
 TE Connectivity Raychem Cable Protection | Natural | Tab | Contacts Not Included | 105 ░C | -55 °C | Polybutylene Terephthalate (PBT) Glass Filled | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | |
 TE Connectivity Raychem Cable Protection | Natural | Tab | Contacts Not Included | 150 °C | -55 °C | Nylon Polyamide (PA) | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm | 2 |
TE Connectivity Raychem Cable Protection | Purple | Tab | Contacts Not Included | 105 ░C | -55 °C | Polybutylene Terephthalate (PBT) Glass Filled | Panel Mount Snap-In | Receptacle | Crimp | 1 | Glow Wire Compliant | Latch Lock | 0.236 in | 6 mm |
