4100N Series
DC Fans Tubeaxial Fan, 119x119x38mm, 24VDC, 274CFM, 90W, 77dBA, 9500RPM, Ball, S-Force
Manufacturer: ebm-papst Inc.
Catalog
DC Fans Tubeaxial Fan, 119x119x38mm, 24VDC, 274CFM, 90W, 77dBA, 9500RPM, Ball, S-Force
Beta
⌘K
DC Fans Tubeaxial Fan, 119x119x38mm, 24VDC, 274CFM, 90W, 77dBA, 9500RPM, Ball, S-Force
DC Fans Tubeaxial Fan, 119x119x38mm, 24VDC, 274CFM, 90W, 77dBA, 9500RPM, Ball, S-Force
DC Fans Tubeaxial Fan, 119x119x38mm, 24VDC, 274CFM, 90W, 77dBA, 9500RPM, Ball, S-Force
| Part | Current Rating (Amps) | Material - Frame | Lifetime @ Temp. | Material - Blade | Voltage Range [Min] | Voltage Range [Max] | Air Flow | Air Flow | Fan Type | Size / Dimension | Size / Dimension [x] | Size / Dimension [y] | Approval Agency | Operating Temperature | Operating Temperature [Min] | Operating Temperature [Max] | RPM | Power (Watts) | Termination | Voltage - Rated | Width [y] | Features | Noise | Static Pressure | Static Pressure | Bearing Type | Lifetime @ Temp. | Air Flow | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | 0.94 A | Metal | Varies Based on Temperature | Plastic | 36 VDC | 60 V | 229.5 CFM | 6.43 m³/min | Tubeaxial | Square | 119 mm | 119 mm | CCC CE CSA EAC UL VDE | (-20 ~ 65°C) | -20 ░C | 65 °C | 7500 RPM | 45 W | 3 Wire Leads | 48 VDC | 38 mm | Auto Restart Speed Sensor (Tach) | 70 dB(A) | 3.111 in H2O | 775 Pa | Ball | ||||
ebm-papst Inc. | ||||||||||||||||||||||||||||||
ebm-papst Inc. | ||||||||||||||||||||||||||||||
ebm-papst Inc. | Aluminum | Polyamide (PA) Nylon | 16 VDC | 30 V | 274 CFM | 7.67 m³/min | Tubeaxial | Square | 119 mm | 119 mm | -4 °F | 167 °F | 9500 RPM | 90 W | 2 Wire Leads | 24 VDC | 38 mm | 77 dB | Ball | 97500 Hrs | 274 CFM | |||||||||
 ebm-papst Inc. | Aluminum | Polyamide (PA) Nylon Fiberglass Reinforced | 9 V | 14 V | 208.9 CFM | 5.85 m³/min | Tubeaxial | Square | 119 mm | 119 mm | (-20 ~ 65°C) | -20 ░C | 65 °C | 6800 RPM | 32 W | 2 Wire Leads | 12 VDC | 38 mm | 67 dB | Ball | 62500 Hrs | 0.86 lb | 390.09 g | |||||||
 ebm-papst Inc. | ||||||||||||||||||||||||||||||
ebm-papst Inc. | Aluminum | Polyamide (PA) Nylon Fiberglass Reinforced | 16 VDC | 30 V | 315 CFM | 8.82 m³/min | Tubeaxial | Square | 119 mm | 119 mm | -4 °F | 167 °F | 11000 RPM | 120 W | 2 Wire Leads | 24 VDC | 38 mm | 80 dB(A) | Ball | |||||||||||
ebm-papst Inc. | 259 CFM | 7.25 mł/min | Tubeaxial | Square | 119 mm | 119 mm | (-20 ~ 65°C) | -20 ░C | 65 °C | 8400 RPM | 62 W | 4 Wire Leads | 48 VDC | 38 mm | PWM Control Speed Sensor (Tach) | 78 dB(A) | Ball |
