PD-SF1212 Series
Manufacturer: Power Dynamics, Inc.
Beta
⌘K
CONN PLUG FMALE 9POS SLDR CUP
| Part | Color | Shielding | Shell Material | Contact Material | Operating Temperature (Min) | Operating Temperature (Max) | Shell Finish | Number of Positions | Current Rating | Primary Material | Material Flammability Rating | Mounting Type | Connector Type | Termination | Ingress Protection Description | Ingress Protection IP Rating | Fastening Type | Orientation | Contact Finish - Mating | Mounting Feature | Voltage Rating | Insert Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Power Dynamics, Inc. | Silver | Unshielded | Brass | Brass | -40 °C | 85 °C | Chrome | 9 | 3 A | Metal | UL94 V-0 | Panel Mount | Female Sockets Plug | Solder Cup | Dust Tight Waterproof | IP67 | Push-Pull | Keyed | Gold | Bulkhead Rear Side Nut | 125 V | Polyphenylene Sulfide PPS |
