T12F Series
Manufacturer: Panduit Corp
Beta
⌘K
SPIRAL WRAP, 0.12 ", 3.2 MM, POLYETHYLENE, BLACK, 100 FT, 30.5 M
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Diameter - Outside, Non-Expanded [diameter] | Diameter - Outside, Non-Expanded [diameter] | Abrasion Protection | Material Flammability Rating | Type | Diameter - Inside, Expanded [diameter] | Diameter - Inside, Expanded [diameter] | Material | Type Attributes | Wall Thickness [custom] | Wall Thickness | Heat Protection | Color | Length | Length | Environment Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panduit Corp | -20 ░C | 50 °C | 0.125 in | 3.18 mm | Abrasion Resistant | UL94 V-0 | Spiral Wrap | 12.7 mm | 0.5 in | Polyethylene (PE) | Harness | 0.03 " | 0.76 mm | Flame Retardant | Black | 100 ' | 30.48 m | |
 Panduit Corp | -40 C | 50 °C | 0.125 in | 3.18 mm | Abrasion Resistant | UL94 HB | Spiral Wrap | 12.7 mm | 0.5 in | Polyethylene (PE) | Harness | 0.03 " | 0.76 mm | Natural | 100 ' | 30.48 m | ||
 Panduit Corp | ||||||||||||||||||
 Panduit Corp | -20 ░C | 50 °C | 0.125 in | 3.18 mm | Abrasion Resistant | UL94 V-0 | Spiral Wrap | 12.7 mm | 0.5 in | Polyethylene (PE) | Harness | 0.03 " | 0.76 mm | Flame Retardant | Natural White | 100 ' | 30.48 m | |
Panduit Corp | -40 C | 50 °C | 0.125 in | 3.18 mm | Abrasion Resistant | UL94 HB | Spiral Wrap | 12.7 mm | 0.5 in | Polyethylene (PE) | Harness | 0.03 " | 0.76 mm | Black | 100 ' | 30.48 m | Weather Resistant |
