628-W7W Series

Manufacturer: EDAC Inc.

Catalog

CONN D-SUB RCPT 7P PNL MNT

Part	Contact Material	Color	Voltage Rating	Dielectric Material	Operating Temperature [Max]	Operating Temperature [Min]	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Contact Finish	Shell Material, Finish	Flange Feature	Mounting Type	Current Rating (Amps)	Number of Positions	Number of Positions [custom]	Number of Positions [custom]	Number of Rows [custom]	Connector Type	Material Flammability Rating	Contact Finish Thickness	Contact Finish Thickness	Ingress Protection	Contact Type	Features	Connector Style	Contact Finish Thickness	Current Rating (Amps)	Termination	Flange Feature
EDAC Inc. 628W7W2-122-2NA	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell (M3)	Panel Mount Through Hole	20A 5A	7	5	2	2	Receptacle Female Sockets	UL94 V-0	5 µin	0.127 µm	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub
EDAC Inc. 628W7W2-222-4NA	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell (M3)	Panel Mount Through Hole		7	5	2	2	Receptacle Female Sockets	UL94 V-0			IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub	Flash	5 A 40 A
EDAC Inc. 628W7W2-624-1N2	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell	Panel Mount Through Hole	10A 5A	7	5	2	2	Receptacle Female Sockets	UL94 V-0	30 Áin	0.76 Ám	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub			Solder	4-40
EDAC Inc. 628W7W2-622-1N2	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell	Panel Mount Through Hole	10A 5A	7	5	2	2	Receptacle Female Sockets	UL94 V-0	30 Áin	0.76 Ám	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub				4-40
EDAC Inc. 628W7W2-124-4N2	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell	Panel Mount Through Hole		7	5	2	2	Receptacle Female Sockets	UL94 V-0	5 µin	0.127 µm	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub		5 A 40 A	Solder	4-40
EDAC Inc. 628W7W2-222-3NA	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell (M3)	Panel Mount Through Hole		7	5	2	2	Receptacle Female Sockets	UL94 V-0			IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub	Flash	5 A 30 A
EDAC Inc. 628W7W2-122-4NA	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell (M3)	Panel Mount Through Hole		7	5	2	2	Receptacle Female Sockets	UL94 V-0	5 µin	0.127 µm	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub		5 A 40 A
EDAC Inc. 628W7W2-124-3NA	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell (M3)	Panel Mount Through Hole		7	5	2	2	Receptacle Female Sockets	UL94 V-0	5 µin	0.127 µm	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub		5 A 30 A	Solder
EDAC Inc. 628W7W2-322-1NA	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell (M3)	Panel Mount Through Hole	10A 5A	7	5	2	2	Receptacle Female Sockets	UL94 V-0	15 µin	0.38 µm	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub
EDAC Inc. 628W7W2-122-3NA	Copper Alloy	Black	125 VDC	Polybutylene Terephthalate (PBT) Glass Filled	85 °C	-25 °C	A DA	2	7W2	Gold	Nickel Plated Steel	Housing/Shell (M3)	Panel Mount Through Hole		7	5	2	2	Receptacle Female Sockets	UL94 V-0	5 µin	0.127 µm	IP67 - Dust Tight Waterproof	Signal and Power	Shielded	Combo D-Sub		5 A 30 A
