8741 Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 4CON 22AWG CHRM
| Part | Conductor Material | Conductor Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Ratings | Number of Conductors | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Usage | Cable Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket Color | Conductor Strand | Wire Gauge | Jacket (Insulation) Material | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Copper Tinned | Poly-Vinyl Chloride (PVC) | 80 °C | -20 ░C | UL Style 2576 | 4 | 0.23 in | 5.84 mm | Audio Control Instrumentation | Multi-Pair | 0.813 mm | 0.032 in | Chrome | Solid | 22 AWG | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft |
Belden Inc. | Copper Tinned | Poly-Vinyl Chloride (PVC) | 80 °C | -20 ░C | UL Style 2576 | 4 | 0.23 in | 5.84 mm | Audio Control Instrumentation | Multi-Pair | 0.813 mm | 0.032 in | Chrome | Solid | 22 AWG | Poly-Vinyl Chloride (PVC) | 152.4 m | 500 ft |
