1019-7511 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMC M STR BHD SP
| Part | Includes | Insertion Loss | Operating Temperature [Min] | Operating Temperature [Max] | Body Finish | Center Contact Plating | Body Material | Dielectric Material | Mating Cycles | Shield Termination | Number of Ports | Connector Type | Fastening Type | Connector Style | Housing Color | Mounting Type | Contact Termination | Impedance | Mounting Feature | Center Contact Material | Frequency - Max [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | 1 Connector 1 Lockwasher 1 Nut | 0.25 dB | -65 ░C | 165 °C | Nickel | Gold | Brass | Polytetrafluoroethylene (PTFE) | 500 | Solder | 1 | Jack Male Pin | Threaded | SMC | Silver | Panel Mount | Solder Cup | 50 Ohms | Bulkhead - Rear Side Nut | Brass | 10 GHz |
