842-008 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 8POS 0.100
| Part | Termination Rows | Material - Insulation | Card Type | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Termination | Read Out | Mounting Type | Contact Material | Contact Finish | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Positions/Bay/Row | Color |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Wire Wrap | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Single | Right Angle Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder Eyelet(s) | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 8 | Green |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 1 | 125 °C | -40 C | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Solder Eyelet(s) | Single | Through Hole | Copper Alloy | Gold | Cantilever | 0.25 Ám | 10 Áin | 8 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 8 | Green |
