325-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 7POS 0.100
| Part | Termination Rows | Material - Insulation | Gender | Number of Rows | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Mounting Type | Card Thickness | Card Thickness | Read Out | Pitch | Pitch | Termination | Color | Card Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Number of Positions | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 1 | Gold | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | -65 ░C | 125 °C | Copper Alloy | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Solder Eyelet(s) | Green | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 7 | 7 | Cantilever |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 1 | Gold | -65 ░C | 125 °C | Copper Alloy | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Solder Eyelet(s) | Green | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 7 | 7 | Cantilever | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 1 | Gold | -65 ░C | 125 °C | Copper Alloy | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Wire Wrap | Green | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 7 | 7 | Cantilever | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 1 | Gold | Flush Mount M3 Threaded Insert Top Opening | -65 ░C | 125 °C | Copper Alloy | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Wire Wrap | Green | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 7 | 7 | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 1 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | -65 ░C | 125 °C | Copper Alloy | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Solder | Green | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 7 | 7 | Cantilever | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 1 | Gold | Flush Mount M3 Threaded Insert Top Opening | -65 ░C | 125 °C | Copper Alloy | Through Hole | 3.18 mm | 0.125 in | Single | 0.1 " | 2.54 mm | Solder | Green | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 7 | 7 | Cantilever |
