ESC227M Series

Manufacturer: KEMET

Catalog

CAP ALUM 220UF 20% 10V RADIAL TH

Part	Ripple Current @ High Frequency	Ripple Current @ Low Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [diameter]	Size / Dimension [diameter]	Polarization	Lifetime @ Temp.	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Voltage - Rated	Package / Case	Capacitance	Mounting Type	Applications	Tolerance	ESR (Equivalent Series Resistance)	Lead Spacing	Lead Spacing	Impedance	Height - Seated (Max) [Max]
KEMET ESC227M010AE3AA	300 mA	270 mA	-40 C	105 ░C	0.248 "	6.3 mm	Polar	2000 Hrs	0.492 in	12.5 mm	10 V	Can Radial	220 µF	Through Hole	General Purpose	20 %	220 mOhm	2.5 mm	0.098 in	220 mOhms
KEMET ESC227M035AH1AA	800 mA	720 mA	-40 C	105 ░C	0.394 in	10 mm	Polar	2000 Hrs	13.5 mm		35 V	Can Radial	220 µF	Through Hole	General Purpose	20 %	69 mOhm	5 mm	0.197 "	69 mOhms	0.531 in
KEMET ESC227M035AH1EA	800 mA	720 mA	-40 C	105 ░C	0.394 in	10 mm	Polar	2000 Hrs	13.5 mm		35 V	Can Radial	220 µF	Through Hole	General Purpose	20 %	69 mOhm	5 mm	0.197 "	69 mOhms	0.531 in
