325-055 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 55POS 0.100
| Part | Termination Rows | Material - Insulation | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Color | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness | Card Thickness | Card Type | Gender | Flange Feature | Number of Positions/Bay/Row | Termination | Contact Finish | Number of Positions | Number of Rows | Read Out | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Green | Cantilever | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Flush Mount M3 Threaded Insert Top Opening | 55 | Solder | Gold | 55 | 1 | Single | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Green | Cantilever | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | 4-40 Flush Mount Threaded Insert Top Opening | 55 | Wire Wrap | Gold | 55 | 1 | Single | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Green | Cantilever | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Flush Mount Top Opening Unthreaded | 55 | Solder Eyelet(s) | Gold | 55 | 1 | Single | Copper Alloy | 0.16 " | 4.06 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Green | Cantilever | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Flush Mount Top Opening Unthreaded | 55 | Wire Wrap | Gold | 55 | 1 | Single | Copper Alloy | 0.16 " | 4.06 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Through Hole | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Green | Cantilever | -65 ░C | 125 °C | 3.18 mm | 0.125 in | Non Specified - Single Edge | Female | Flush Mount M3 Threaded Insert Top Opening | 55 | Solder Eyelet(s) | Gold | 55 | 1 | Single | Copper Alloy |
