5680202 Series

Manufacturer: DIALIGHT

Catalog

LED CBI 3MM QUAD LVL G/Y/R/X RA

Part	Lens Size	Lens Size	Lens Style	Mounting Type	Viewing Angle	Voltage Rating	Wavelength - Peak	Lens Type	Millicandela Rating	Current	Configuration	Color	Millicandela Rating [custom]	Millicandela Rating [custom]	Millicandela Rating [custom]	Lens Size [diameter]
DIALIGHT 5680202805F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole
DIALIGHT 5680202323F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.8 V 1.9 V	565 nm 585 nm	Diffused Tinted	1.6 mcd	2 mA	4 High	Green (x 2) Yellow (x 2)
DIALIGHT 5680202122F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.9 V	565 nm		1.6 mcd	2 mA	4 High	Green
DIALIGHT 5680202213F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.7 V 1.8 V 1.9 V	565 nm 585 nm 635 nm				4 High	Green (x 2) Red (x 1) Yellow (x 1)	1.6 mcd	1.6 mcd	1.6 mcd
DIALIGHT 5680202231F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.7 V 1.8 V 1.9 V	565 nm 585 nm 635 nm				4 High	Green (x 2) Red (x 1) Yellow (x 1)	1.6 mcd	1.6 mcd	1.6 mcd
DIALIGHT 5680202102F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.7 V 1.9 V	565 nm 635 nm				4 High	Blank (x 1) Green (x 2) Red (x 1)	1.6 mcd	1.6 mcd
DIALIGHT 5680202133F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.7 V 1.8 V 1.9 V	565 nm 585 nm 635 nm				4 High	Green (x 1) Red (x 1) Yellow (x 2)	1.6 mcd	1.6 mcd	1.6 mcd
DIALIGHT 5680202001F			Round with Domed Top	Right Angle Through Hole	60 °	1.7 V 1.9 V	565 nm 635 nm				4 High	Blank (x 2) Green (x 1) Red (x 1)	1.6 mcd	1.6 mcd		3 mm
DIALIGHT 5680202211F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.7 V 1.9 V	565 nm 635 nm				4 High	Green (x 2) Red (x 2)	1.6 mcd	1.6 mcd
DIALIGHT 5680202223F	3 mm	T-1	Round with Domed Top	Right Angle Through Hole	60 °	1.8 V 1.9 V	565 nm 585 nm		1.6 mcd 1.6 mcd		4 High	Green (x 3) Yellow (x 1)
