TFA0948 Series

Catalog

FAN AXIAL 92X38MM 48VDC WIRE

Part	Lifetime @ Temp.	Current Rating (Amps)	Material - Blade	Voltage Range [Min]	Voltage Range [Max]	Material - Frame	Air Flow	Air Flow	Width [y]	Voltage - Rated	Features	Static Pressure	Static Pressure	Approval Agency	Size / Dimension [y]	Size / Dimension [x]	Power (Watts)	RPM	Fan Type	Termination	Weight	Weight	Noise	Bearing Type	Operating Temperature [Max]	Operating Temperature [Min]	Ingress Protection
Delta Electronics TFA0948AE	70000 Hrs	120 mA	Plastic	28 V	62 VDC	Plastic	1.88 m³/min	67.1 CFM	38 mm	48 VDC	Locked Rotor Protection PWM Control Speed Sensor (Tach)	179.3 Pa	0.72 in H2O	CE CSA UL VDE	92 mm	92 mm	5.76 W	5000 RPM	Tubeaxial	4 Wire Leads	210.01 g	0.463 lb	49.8 dB(A)	Ball	70 °C	-10 °C
Delta Electronics TFA0948AE-EP	70000 Hrs	120 mA	Plastic	36 VDC	57 VDC	Plastic	1.89 m³/min	67.6 CFM	38 mm	48 VDC	GR-487 (Salt Fog Protection) Locked Rotor Protection PWM Control Speed Sensor (Tach)	172.1 Pa	0.691 in H2O	CE cURus VDE	92 mm	92 mm	5.76 W	5000 RPM	Tubeaxial	4 Wire Leads	250.84 g	0.553 lb	49.5 dB	Ball			IP56 - Dust Protected Water Resistant
