629-M09 Series
Manufacturer: EDAC Inc.
Beta
⌘K
629M SERIES RIGHT ANGLE D-SUB PL
| Part | Contact Material | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Features | Backset Spacing | Backset Spacing | Flange Feature | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Material Flammability Rating | Contact Type | Number of Positions | Termination | Connector Style | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Number of Rows [custom] | Shell Material, Finish | Contact Finish | Connector Type | Current Rating (Amps) | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | Housing/Shell | 4-40 | 30 Áin | 0.76 Ám | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Nickel Plated Steel | Gold | Plug Male Pins | 5 A | |
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Board Lock Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | 4-40 | 15 µin | 0.38 µm | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Nickel Plated Steel | Gold | Plug Male Pins | 5 A | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Board Lock Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | 4-40 | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Gold | Plug Male Pins | 5 A | Flash | ||||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | Housing/Shell | 4-40 | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Gold | Plug Male Pins | 5 A | Flash | |||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | Board Side (4-40) | 15 µin | 0.38 µm | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Nickel Plated Steel | Gold | Plug Male Pins | 5 A | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | 4-40 | 15 µin | 0.38 µm | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Nickel Plated Steel | Gold | Plug Male Pins | 5 A | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | Board Side (4-40) | 15 µin | 0.38 µm | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Gold | Plug Male Pins | 5 A | |||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Shielded | 9.4 mm | 0.37 in | Housing/Shell (Unthreaded) | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Nickel Plated Steel | Gold | Plug Male Pins | 5 A | Flash | |||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | Board Side (4-40) | 30 Áin | 0.76 Ám | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Nickel Plated Steel | Gold | Plug Male Pins | 5 A | ||
 EDAC Inc. | Copper Alloy | Polyamide (PA6T) Nylon 6T | Black | -55 C | 125 °C | Grounding Indents Mounting Brackets Shielded | 9.4 mm | 0.37 in | 4-40 | Right Angle Through Hole | UL94 V-0 | Signal | 9 | Solder | Combo D-Sub | 1 | DE E | 2 | Nickel Plated Steel | Gold | Plug Male Pins | 5 A | Flash |
