282842 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
TERM BLK 8P SIDE ENTRY 10MM PCB
| Part | Features | Number of Levels | Pitch [x] | Pitch [x] | Voltage | Screw Thread | Positions Per Level | Color | Mating Orientation | Mounting Type | Screw Material - Plating | Torque - Screw | Torque - Screw | Wire Termination | Clamp Material - Plating | Contact Material - Plating [custom] | Current | Wire Gauge [Max] | Wire Gauge [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Interlocking (Side) | 1 | 0.394 in | 10 mm | 600 V | M3 | 8 | Green | Horizontal with Board | Through Hole | Brass - Nickel Plated | 0.79 Nm | 7 Lb-In | Screw - Rising Cage Clamp | Brass - Nickel Plated | Brass - Tin Plated | 17.5 A | 30 AWG | 12 AWG |
 TE Connectivity Raychem Cable Protection | Interlocking (Side) | 1 | 0.394 in | 10 mm | 600 V | M3 | 3 | Green | Horizontal with Board | Through Hole | Brass - Nickel Plated | 0.79 Nm | 7 Lb-In | Screw - Rising Cage Clamp | Brass - Nickel Plated | Brass - Tin Plated | 17.5 A | 30 AWG | 12 AWG |
