MCS-24D Series

Catalog

RELAY TIME DELAY 45SEC CHAS MT

Part	Function	Termination Style	Timing Initiate Method	Voltage - Supply	Relay Type	Delay Time (Minimum)	Delay Time (Maximum)	Circuit	Mounting Type	Timing Adjustment Method	Quick Connect Size (0.250")	Delay Time Mode	Delay Time (Fixed)
R-K Electronics, Inc. MCS-24D-2S	On-Delay	Screw Terminal	Input Voltage	24 VDC	Solid State Relay	0.1 Sec	45 Sec	SPST-NO (1 Form A)	Chassis Mount	Screwdriver Slot
R-K Electronics, Inc. MCS-24D-1T-.1	On-Delay	Quick Connect	Input Voltage	24 VDC	Solid State Relay			SPST-NO (1 Form A)	Chassis Mount	Fixed	0.25 in	Fixed	0.1 Sec
R-K Electronics, Inc. MCS-24D-4T	On-Delay	Quick Connect	Input Voltage	24 VDC	Solid State Relay			SPST-NO (1 Form A)	Chassis Mount	External Resistor	0.25 in
R-K Electronics, Inc. MCS-24D-3S	On-Delay	Screw Terminal	Input Voltage	24 VDC	Solid State Relay	0.1 Sec	300 Sec	SPST-NO (1 Form A)	Chassis Mount	External Resistor Screwdriver Slot
R-K Electronics, Inc. MCS-24D-3T	On-Delay	Quick Connect	Input Voltage	24 VDC	Solid State Relay	0.1 Sec	300 Sec	SPST-NO (1 Form A)	Chassis Mount	External Resistor Screwdriver Slot	0.25 in
R-K Electronics, Inc. MCS-24D-4XS-A4051	On-Delay	Screw Terminal	Input Voltage	24 VDC	Solid State Relay			SPST-NO (1 Form A)	Chassis Mount	External Resistor
R-K Electronics, Inc. MCS-24D-2T	On-Delay	Quick Connect	Input Voltage	24 VDC	Solid State Relay	0.1 Sec	45 Sec	SPST-NO (1 Form A)	Chassis Mount	Screwdriver Slot	0.25 in
