OD2-P30 Series

Catalog

SEN DISP 30MM +/- 4MM PNP

Part	Mounting Type	Type	Ingress Protection	Installation Distance [Max]	Installation Distance [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Supply [Max]	Voltage - Supply [Min]	Termination Style
SICK, Inc. 6036578	Chassis Mount	2D Laser Displacement Sensor	IP67 - Dust Tight Waterproof	34 mm	26 mm	40 °C	-10 °C	24 V	12 VDC	Cable Leads
SICK, Inc. 6036582	Chassis Mount	2D Laser Displacement Sensor	IP67 - Dust Tight Waterproof	34 mm	26 mm	40 °C	-10 °C	24 V	12 VDC	Connector
SICK, Inc. 6036581	Chassis Mount	2D Laser Displacement Sensor	IP67 - Dust Tight Waterproof	34 mm	26 mm	40 °C	-10 °C	24 V	12 VDC	Connector
SICK, Inc. 6036577	Chassis Mount	2D Laser Displacement Sensor	IP67 - Dust Tight Waterproof	34 mm	26 mm	40 °C	-10 °C	24 V	12 VDC	Cable Leads
SICK, Inc. OD2-P30W04U2	Chassis Mount	2D Laser Displacement Sensor	IP67 - Dust Tight Waterproof	34 mm	26 mm	40 °C	-10 °C	24 V	12 VDC	Cable Leads
SICK, Inc. 6036583	Chassis Mount	2D Laser Displacement Sensor	IP67 - Dust Tight Waterproof	34 mm	26 mm	40 °C	-10 °C	24 V	12 VDC	Connector
