ESS30 Series
Manufacturer: ETA-USA
Beta
⌘K
AC/DC CONVERTER 36V 29W
| Part | Applications | Standard Number | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Isolation | Efficiency | Type | Mounting Type | Power (Watts) | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Features | Number of Outputs | Voltage - Output 1 [custom] | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 1 | Current - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ETA-USA | Industrial ITE (Commercial) | 60950-1; UL 508 | 264 VAC 370 VDC | 85 VAC 110 VDC | 3000 V | 90.5 % | Enclosed | Chassis Mount | 29 W | 33 mm | 98 mm | 3.86 " | 68 mm | 2.68 in | 1.3 in | Adjustable Output Remote Sense Universal Input | 1 | 36 V | CE CSA cURus SEMKO | 71 °C | -10 °C | ||
ETA-USA | Industrial ITE (Commercial) | 60950-1; UL 508 | 264 VAC 370 VDC | 85 VAC 110 VDC | 3000 V | 90.5 % | Enclosed | Chassis Mount | 30 Watts | 33 mm | 98 mm | 3.86 " | 68 mm | 2.68 in | 1.3 in | Adjustable Output Remote Sense Universal Input | 1 | CE CSA cURus SEMKO | 71 °C | -10 °C | 5 V | 6 A | |
ETA-USA | Industrial ITE (Commercial) | 60950-1; UL 508 | 264 VAC 370 VDC | 85 VAC 110 VDC | 3000 V | 90.5 % | Enclosed | Chassis Mount | 31 W | 33 mm | 98 mm | 3.86 " | 68 mm | 2.68 in | 1.3 in | Adjustable Output Remote Sense Universal Input | 1 | CE CSA cURus SEMKO | 71 °C | -10 °C | 48 V | 650 mA |
