NQ Series
Manufacturer: Amphenol Anytek
Beta
⌘K
TERM BLK 2POS SIDE ENTRY 3MM SMD
| Part | Mating Orientation | Current | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material - Plating | Wire Termination | Color | Voltage | Pitch [x] | Pitch [x] | Mounting Type | Housing Material | Wire Gauge [Min] | Wire Gauge [Max] | Positions Per Level | Number of Levels | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Anytek | Horizontal with Board | 3 A | -40 °C | 130 °C | Copper Alloy - Tin Plated | Push-In Spring Screwless - Leg Spring | Natural | 150 V | 3 mm | 0.118 in | Surface Mount | Liquid Crystal Polymer (LCP) | 22 AWG | 26 AWG | 2 | 1 | |
 Amphenol Anytek | Horizontal with Board | 9 A | -45 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Natural | 300 V | 4 mm | 0.157 in | Surface Mount | Liquid Crystal Polymer (LCP) | 17.5 AWG | 24 AWG | 3 | 1 | ||
 Amphenol Anytek | Horizontal with Board | 9 A | -40 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Black | 600 V | Surface Mount | Liquid Crystal Polymer (LCP) | 17.5 AWG | 22 AWG | 1 | 1 | ||||
 Amphenol Anytek | Horizontal with Board | 9 A | -45 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Natural | 300 V | 4 mm | 0.157 in | Surface Mount | Liquid Crystal Polymer (LCP) | 17.5 AWG | 24 AWG | 2 | 1 | ||
Amphenol Anytek | Horizontal with Board | 9 A | -40 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Gray | 300 V | 4 mm | 0.157 in | Surface Mount | Liquid Crystal Polymer (LCP) | 17.5 AWG | 22 AWG | 3 | 1 | Solder Retention | |
 Amphenol Anytek | Horizontal with Board | 3 A | -40 °C | 130 °C | Copper Alloy - Tin Plated | Push-In Spring Screwless - Leg Spring | Natural | 150 V | 3 mm | 0.118 in | Surface Mount | Liquid Crystal Polymer (LCP) | 22 AWG | 26 AWG | 3 | 1 | |
 Amphenol Anytek | Horizontal with Board | 5 A | -45 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Black | 150 V | 2.5 mm | 0.098 in | Surface Mount | Liquid Crystal Polymer (LCP) | 20 AWG | 24 AWG | 6 | 1 | Solder Retention | |
 Amphenol Anytek | Horizontal with Board | 5 A | -45 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Black | 150 V | 2.5 mm | 0.098 in | Surface Mount | Liquid Crystal Polymer (LCP) | 20 AWG | 24 AWG | 2 | 1 | ||
 Amphenol Anytek | Horizontal with Board | 9 A | -40 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Black | 600 V | 4 mm | 0.157 in | Surface Mount | Liquid Crystal Polymer (LCP) | 17.5 AWG | 22 AWG | 3 | 1 | ||
 Amphenol Anytek | Horizontal with Board | 5 A | -45 °C | 130 °C | Push-In Spring Screwless - Leg Spring | Black | 150 V | 2.5 mm | 0.098 in | Surface Mount | Liquid Crystal Polymer (LCP) | 20 AWG | 24 AWG | 3 | 1 | Solder Retention |
