PEG124Y Series

Manufacturer: KEMET

Catalog

CAP ALUM 47UF 450V AXIAL TH

Part	Tolerance [Min]	Tolerance [Max]	Capacitance	Lifetime @ Temp.	Voltage - Rated	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [diameter]	Size / Dimension [diameter]	Applications	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Ripple Current @ High Frequency	Package / Case	Polarization	Mounting Type	ESR (Equivalent Series Resistance)	Ripple Current @ Low Frequency	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Tolerance	Height - Seated (Max) [Max]
KEMET PEG124YL2470QL1	-10 %	30 %	47 µF	2000 Hrs	450 V	125 °C	-40 C	20 mm	0.787 "	General Purpose	1.811 in	46 mm	392.08 mA	Axial Can	Polar	Through Hole	1.2 Ohm	377 mA
KEMET PEG124YB1220QT1	-10 %	30 %	2.2 µF	5000 Hrs	450 V	105 ░C	-40 C	10 mm	0.394 in	General Purpose			290 mA	Axial Can	Polar	Through Hole	24 Ohm	43 mA	29 mm	1.142 in
KEMET PEG124YB1220QL1	-10 %	30 %	2.2 µF	5000 Hrs	450 V	105 ░C	-40 C	10 mm	0.394 in	General Purpose			290 mA	Axial Can	Polar	Through Hole	24 Ohm	43 mA	29 mm	1.142 in
KEMET PEG124YB1330QT1	-10 %	30 %	3.3 µF	5000 Hrs	450 V	105 ░C	-40 C	10 mm	0.394 in	General Purpose			380 mA	Axial Can	Polar	Through Hole	17 Ohm	55 mA	29 mm	1.142 in
KEMET PEG124YD1470QL1			4.7 µF	5000 Hrs	450 V	105 ░C	-40 C		0.512 in	General Purpose			82.16 mA	Axial Can	Polar	Through Hole	11 Ohm	79 mA			13 mm	1.142 in	29 mm	20 %
KEMET PEG124YA1100QL1			1 µF	5000 Hrs	450 V	105 ░C	-40 C	10 mm	0.394 in	General Purpose		0.787 in	31.2 mA	Axial Can	Polar	Through Hole	49 Ohm	30 mA						20 %	20 mm
KEMET PEG124YB1330QL1	-10 %	30 %	3.3 µF	5000 Hrs	450 V	105 ░C	-40 C	10 mm	0.394 in	General Purpose			380 mA	Axial Can	Polar	Through Hole	17 Ohm	55 mA	29 mm	1.142 in
