16_SMB-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
16_SMB-50-2-40/111_NE
| Part | Body Material | Mating Cycles | Dielectric Material | Center Contact Plating | Body Finish | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Center Contact Material | Contact Termination | Shield Termination | Cable Group | Frequency - Max [Max] | Housing Color | Connector Style | Impedance | Number of Ports | Mounting Type | Fastening Type | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | Brass | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | Plug Male Pin | Beryllium Copper | Crimp | Crimp | 188 316 RG-174 | 4 GHz | Gold | SMB | 50 Ohms | 1 | Free Hanging (In-Line) Right Angle | Snap-On | |
 Huber+Suhner, Inc. | Brass | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | Plug Male Pin | Beryllium Copper | Crimp | Crimp | RG-178 | 4 GHz | Gold | SMB | 50 Ohms | 1 | Free Hanging (In-Line) Right Angle | Snap-On | 196 |
 Huber+Suhner, Inc. | Brass | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | Plug Male Pin | Beryllium Copper | Solder | Crimp | RD-316 | 4 GHz | Gold | SMB | 50 Ohms | 1 | Free Hanging (In-Line) Right Angle | Snap-On | |
 Huber+Suhner, Inc. | Brass | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | Plug Male Pin | Beryllium Copper | Solder | Crimp | 316 RG-188 RG-405 | 4 GHz | Gold | SMB | 50 Ohms | 1 | Free Hanging (In-Line) Right Angle | Snap-On | 0.085 in |
 Huber+Suhner, Inc. | Brass | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | Plug Male Pin | Beryllium Copper | Crimp | Crimp | 188 316 RG-174 | 4 GHz | Gold | SMB | 50 Ohms | 1 | Free Hanging (In-Line) Right Angle | Snap-On | |
 Huber+Suhner, Inc. | Brass | 500 | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Gold | -65 ░C | 165 °C | Plug Male Pin | Beryllium Copper | Solder | Crimp | RG-178 | 4 GHz | Gold | SMB | 50 Ohms | 1 | Free Hanging (In-Line) Right Angle | Snap-On | 196 |
