842-020 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 20POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Mounting Type | Contact Type | Number of Rows [custom] | Number of Positions | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Contact Material | Color | Termination | Pitch | Pitch | Card Type | Card Thickness [Max] | Card Thickness [Min] | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Through Hole | Cantilever | 2 | 20 | 10 | 0.25 Ám | 10 Áin | 125 °C | -40 C | Dual | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Female | Copper Alloy | Green | Solder Eyelet(s) | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Right Angle Through Hole | Cantilever | 20 | 20 Bay/Row | 0.25 Ám | 10 Áin | 125 °C | -40 C | Single | Gold | Female | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Board Edge Straddle Mount | Cantilever | 2 | 20 | 10 | 0.25 Ám | 10 Áin | 125 °C | -40 C | Dual | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Female | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Cantilever | 20 | 20 Bay/Row | 0.25 Ám | 10 Áin | 125 °C | -40 C | Single | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Female | Copper Alloy | Green | Solder Eyelet(s) | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Cantilever | 20 | 20 Bay/Row | 0.25 Ám | 10 Áin | 125 °C | -40 C | Single | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Female | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Board Edge Straddle Mount | Cantilever | 2 | 20 | 10 | 0.25 Ám | 10 Áin | 125 °C | -40 C | Dual | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Female | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Cantilever | 20 | 20 Bay/Row | 0.25 Ám | 10 Áin | 125 °C | -40 C | Single | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Female | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Single Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Through Hole | Cantilever | 2 | 20 | 10 | 0.25 Ám | 10 Áin | 125 °C | -40 C | Dual | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Female | Copper Alloy | Green | Wire Wrap | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Through Hole | Cantilever | 2 | 20 | 10 | 0.25 Ám | 10 Áin | 125 °C | -40 C | Dual | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Female | Copper Alloy | Green | Wire Wrap | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Right Angle Through Hole | Cantilever | 2 | 20 | 10 | 0.25 Ám | 10 Áin | 125 °C | -40 C | Dual | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Female | Copper Alloy | Green | Solder | 0.1 " | 2.54 mm | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
