MPC85 Series

Manufacturer: Freescale Semiconductor - NXP

Catalog

IC MPU MPC8XX 50MHZ 357BGA

...

Part	Mounting Type	Voltage - I/O	Supplier Device Package	Co-Processors/DSP	Graphics Acceleration	Package / Case	Core Processor	RAM Controllers	Additional Interfaces	Speed	Number of Cores/Bus Width	Operating Temperature [Max]	Operating Temperature [Min]	Ethernet	Security Features	Ethernet	USB	SATA
Freescale Semiconductor - NXP MPC855TCZQ50D4	Surface Mount	3.3 V	357-PBGA (25x25)	Communications CPM		357-BBGA	MPC8xx	DRAM	HDLC/SDLC I2C IrDA PCMCIA SPI TDM UART/USART	50 MHz	1 Core 32 Bit	95 °C	-40 °C
Freescale Semiconductor - NXP MPC8541VTAPF
Freescale Semiconductor - NXP MPC8540CPX667JB	Surface Mount	2.5 V 3.3 V	783-FCPBGA (29x29)			783-BFBGA FCBGA	PowerPC e500	DDR SDRAM	DUART I2C PCI RapidIO	667 MHz	1 Core 32 Bit	105 °C	-40 °C	10/100/1000Mbps (2) 10/100Mbps (1)
Freescale Semiconductor - NXP MPC8541EVTALF	Surface Mount	2.5 V 3.3 V	783-FCPBGA (29x29)	SEC Security		783-BBGA FCBGA	PowerPC e500	DDR SDRAM	DUART I2C PCI	667 MHz	1 Core 32 Bit	105 °C	0 °C	2	Cryptography Random Number Generator	10 Mbps 100 Mbps 1000 Mbps
Freescale Semiconductor - NXP MPC8544VTALFA	Surface Mount	1.8 V 2.5 V 3.3 V	783-FCPBGA (29x29)	Signal Processing SPE		783-BBGA FCBGA	PowerPC e500	DDR DDR2 SDRAM	DUART I2C PCI	667 MHz	1 Core 32 Bit	105 °C	0 °C	2		10 Mbps 100 Mbps 1000 Mbps
Freescale Semiconductor - NXP MPC8536ECVTAULA	Surface Mount	1.8 V 2.5 V 3.3 V	783-FCPBGA (29x29)	SEC Security		783-BBGA FCBGA	PowerPC e500		DUART I2C MMC/SD PCI SPI	1.333 GHz	1 Core 32 Bit	105 °C	-40 °C	2	Cryptography	10 Mbps 100 Mbps 1000 Mbps	USB 2.0 (3)	SATA 3Gbps (2)
Freescale Semiconductor - NXP MPC8548VTAUJD	Surface Mount	1.8 V 2.5 V 3.3 V	783-FCPBGA (29x29)	Signal Processing SPE		783-BBGA FCBGA	PowerPC e500	DDR DDR2 SDRAM	DUART I2C PCI RapidIO	1.333 GHz	1 Core 32 Bit	105 °C	0 °C	4		10 Mbps 100 Mbps 1000 Mbps
Freescale Semiconductor - NXP MPC8540PX833LC	Surface Mount	2.5 V 3.3 V	783-FCPBGA (29x29)			783-BFBGA FCBGA	PowerPC e500	DDR SDRAM	DUART I2C PCI RapidIO	833 MHz	1 Core 32 Bit	105 °C	0 °C	10/100/1000Mbps (2) 10/100Mbps (1)
Freescale Semiconductor - NXP MPC8560VT667LC	Surface Mount	2.5 V 3.3 V	783-FCPBGA (29x29)	Communications CPM		783-BFBGA FCBGA	PowerPC e500	DDR SDRAM	I2C PCI RapidIO SPI TDM UART	667 MHz	1 Core 32 Bit	105 °C	0 °C	2		10 Mbps 100 Mbps 1000 Mbps
Freescale Semiconductor - NXP MPC8555VTALF	Surface Mount	2.5 V 3.3 V	783-FCPBGA (29x29)	Communications CPM		783-BBGA FCBGA	PowerPC e500	DDR SDRAM	DUART I2C PCI SPI TDM UART	667 MHz	1 Core 32 Bit	105 °C	0 °C	2		10 Mbps 100 Mbps 1000 Mbps	USB 2.0 (1)
