151192 Series

2.00mm Pitch Milli-Grid Receptacle Housing, Dual Row, 10 Circuits, Black, Glow-Wire Capable

Manufacturer: Molex

Catalog

2.00mm Pitch Milli-Grid Receptacle Housing, Dual Row, 10 Circuits, Black, Glow-Wire Capable

Part	Number of Positions	Contact Termination	Number of Rows [custom]	Pitch [x]	Pitch [x]	Color	Connector Type	Insulation Material	Mounting Type	Contact Type	Fastening Type	Operating Temperature [Min]	Operating Temperature [Max]	Note	Row Spacing	Row Spacing	Number of Positions [custom]
Molex 1511920016	16	Crimp	2	0.079 in	2 mm	Black	Receptacle	Polyester	Free Hanging (In-Line)	Female Socket	Latch Holder	-55 C	105 ░C
Molex 1511920034		Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C	Contacts Not Included	2 mm	0.079 in	34
Molex 1511920042	42	Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C	Contacts Not Included	2 mm	0.079 in
Molex 1511920036	36	Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C	Contacts Not Included	2 mm	0.079 in
Molex 1511920050	50	Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C	Contacts Not Included	2 mm	0.079 in
Molex 1511920012	12	Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C		2 mm	0.079 in
Molex 1511920048	48	Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C		2 mm	0.079 in
Molex 1511920024	24	Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C		2 mm	0.079 in
Molex 1511920010	10	Crimp	2	0.079 in	2 mm	Black	Receptacle	Polyester Glass Filled	Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C	Contacts Not Included	2 mm	0.079 in
Molex 1511920040	40	Crimp	2	0.079 in	2 mm	Black	Receptacle		Free Hanging (In-Line)	Female Socket	Friction Lock	-55 C	105 ░C		2 mm	0.079 in

Catalog

2.00mm Pitch Milli-Grid Receptacle Housing, Dual Row, 10 Circuits, Black, Glow-Wire Capable
