Z-PACK 2mm HM Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN RECEPT 88POS 2MM PRESS-FIT
| Part | Current Rating (Amps) | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Pitch [x] | Pitch [x] | Number of Positions Loaded | Contact Finish | Termination | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Connector Type | Number of Rows | Connector Style | Connector Usage | Tool Type | For Use With/Related Products | Features | Specifications | Accessory Type | Number of Rows | Number of Positions [custom] | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 1.5 A | 750 Vrms | -55 C | 125 °C | 88 | 0.079 in | 2 mm | All | Gold | Press-Fit | 30 Áin | 0.76 Ám | Board Edge Right Angle Through Hole | Receptacle Female Sockets | 8 | F 11 | |||||||||
 TE Connectivity AMP Connectors | 1.5 A | 500 VAC | -55 C | 125 °C | 110 | 0.079 in | 2 mm | All | Gold | Press-Fit | 30 Áin | 0.76 Ám | Through Hole | Receptacle Female Sockets | 5 | A 22 | Backplane | ||||||||
 TE Connectivity AMP Connectors | Extraction Tool | Terminals | |||||||||||||||||||||||
 TE Connectivity AMP Connectors | 1.5 A | 500 VAC | -55 C | 125 °C | 125 | 0.079 in | 2 mm | All | Gold | Press-Fit | 50 µin | 1.27 µm | Right Angle Through Hole | Receptacle Female Sockets | 5 | B 25 | Upper Shield | ||||||||
 TE Connectivity AMP Connectors | Z-Pack Series | Blue | Coding Keys | ||||||||||||||||||||||
 TE Connectivity AMP Connectors | Z-Pack Series | Gray | Coding Keys | ||||||||||||||||||||||
 TE Connectivity AMP Connectors | 125 | 0.079 in | 2 mm | All | Press-Fit | Through Hole | Header Male Pins | 5 | B 25 | Backplane | |||||||||||||||
 TE Connectivity AMP Connectors | 1.5 A | 500 VAC | -55 C | 125 °C | 0.079 in | 2 mm | All | Gold | Press-Fit | 30 Áin | 0.76 Ám | Through Hole | Header Male Pins | A 22 | Backplane | 5 + 2 | 110 | 44 | |||||||
 TE Connectivity AMP Connectors | 125 | 0.079 in | 2 mm | All | Gold | Press-Fit | 30 Áin | 0.76 Ám | Through Hole | Header Male Pins | 5 | B 25 | Backplane | ||||||||||||
 TE Connectivity AMP Connectors | 144 | 0.079 in | 2 mm | All | Gold | Press-Fit | 30 Áin | 0.76 Ám | Board Edge Right Angle Through Hole | Receptacle Female Sockets | 12 | B 12 | Backplane |
