BCM380 Series

Catalog

DC DC CONVERTER 47.5V 1221W

Part	Voltage - Input (Max) [Max]	Mounting Type	Features	Number of Outputs	Voltage - Input (Min) [Min]	Package / Case	Voltage - Isolation	Type	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage - Output 1	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Power (Watts)	Approval Agency	Current - Output (Max) [Max]	Efficiency
Vicor Corporation BCM380P475M1K2A30	410 V	Through Hole	Adjustable Output	1	260 V	9-DIP Module	4.242 kV	Isolated Module	7.3 mm	0.9 in	2.49 "	63.3 mm	22.8 mm	0.29 in	47.5 V	-55 C	125 °C	ITE (Commercial)	1221 W	CE cTUVus cURus	25.7 A	97.7 %
Vicor Corporation BCM380P475T800A3R	410 V	Through Hole	OCP OTP OVP SCP UVLO	1	260 V	9-DIP Module	4.242 kV	Bus Converter Module	7.3 mm	0.9 in	2.49 "	63.3 mm	22.8 mm	0.29 in	47.5 V	-40 C	125 °C	ITE (Commercial)	800 W		16.9 A	97.7 %
Vicor Corporation BCM380P475T800A31	410 V	Through Hole	OCP OTP OVP SCP UVLO	1	260 V	Module	4.242 kV	Bus Converter Module	7.3 mm	0.9 in	2.49 "	63.3 mm	22.8 mm	0.29 in	47.5 V	-40 C	125 °C	ITE (Commercial)	800 W		16.9 A	97.5 %
Vicor Corporation BCM380P475T1K2A3R	410 V	Through Hole	OCP OTP OVP SCP UVLO	1	260 V	9-DIP Module	4.242 kV	Bus Converter Module	7.3 mm	0.9 in	2.49 "	63.3 mm	22.8 mm	0.29 in	47.5 V	-40 C	125 °C	ITE (Commercial)	1200 W		25.7 A	97.9 %
Vicor Corporation BCM380P475T800A30	410 V	Through Hole	OCP OTP OVP SCP UVLO	1	260 V	9-DIP Module	4.242 kV	Bus Converter Module	7.3 mm	0.9 in	2.49 "	63.3 mm	22.8 mm	0.29 in	47.5 V	-40 C	125 °C	ITE (Commercial)	800 W		16 A	97.5 %
Vicor Corporation BCM380P475M800A30
