053462 Series
Manufacturer: Molex
Beta
⌘K
2.00MM PITCH IEEE 1394-1995 SHIE
| Part | Connector Type | Contact Finish | Mounting Type | Number of Positions | Termination | Features | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Insulation Color | Number of Ports | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Shielding | Gender | Number of Contacts [custom] | Shell/Shielding Material | Material Flammability Rating | Voltage - Rated | Mounting Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Multi-Purpose | Gold | Surface Mount Right Angle Through Hole | 6 | Solder | Board Guide Board Lock | Receptacle | 0.76 Ám | 30 Áin | ||||||||||||
 Molex | Firewire (IEEE 1394) | Gold | Surface Mount Right Angle Through Hole | Solder | Black | 1 | 1.5 A | 85 °C | -40 °C | Shielded | Receptacle | 6 | Phosphor Bronze | UL94 V-0 | 40 V | Horizontal |
