ADS2806 Series

Catalog

IC ADC 12BIT PIPELINED 64HTQFP

Part	Architecture	Ratio - S/H:ADC	Voltage - Supply, Analog	Input Type	Mounting Type	Data Interface	Voltage - Supply, Digital [Min]	Voltage - Supply, Digital [Max]	Sampling Rate (Per Second)	Number of Bits	Reference Type	Configuration	Package / Case	Supplier Device Package	Features	Number of A/D Converters	Operating Temperature [Max]	Operating Temperature [Min]	Number of Inputs	Utilized IC / Part	Supplied Contents	Input Range [Max]	Input Range [Min]	Power (Typ) @ Conditions
Texas Instruments ADS2806Y/1K5	Pipelined	1:1	5 V	Differential Single Ended	Surface Mount	Parallel	3 V	5 V	32 M	12 bits	External Internal	S/H-ADC	64-PowerTQFP	64-HTQFP (10x10)	Simultaneous Sampling	2	85 °C	-40 °C	2
Texas Instruments ADS2806Y/250	Pipelined	1:1	5 V	Differential Single Ended	Surface Mount	Parallel	3 V	5 V	32 M	12 bits	External Internal	S/H-ADC	64-PowerTQFP	64-HTQFP (10x10)	Simultaneous Sampling	2	85 °C	-40 °C	2
Texas Instruments ADS2806-EVM						Parallel			32 M	12 bits						2				ADS2806	Board(s)	3 dBm	2 Vpp	450 mW
