ECW-FA Series

Manufacturer: Panasonic Industrial Automation Sales

Catalog

CAP FILM 0.15UF 5% 630VDC RADIAL

Part	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Capacitance	Dielectric Material	Applications	Package / Case	Lead Spacing	Lead Spacing	Mounting Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Tolerance	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Voltage Rating - AC
Panasonic Industrial Automation Sales ECW-FA2J154JQ	6 mm	18.2 mm	0.236 in	0.717 in	0.15 ÁF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	15 mm	0.591 in	Through Hole	16.2 mm	0.638 in	-40 °C	105 ░C	PC Pins	5 %
Panasonic Industrial Automation Sales ECW-FA2J225JB	16.3 mm	26 mm	0.642 in	1.024 in	2.2 µF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	22.5 mm	0.886 in	Through Hole	26.4 mm	1.039 in	-40 °C	105 ░C	PC Pins	5 %
Panasonic Industrial Automation Sales ECW-FA2J185JQ	14.8 mm	26 mm			1.8 µF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	22.5 mm	0.886 in	Through Hole	26.8 mm	1.055 in	-40 °C	105 ░C	PC Pins	5 %	1.024 "	0.583 in
Panasonic Industrial Automation Sales ECW-FA2J154J5	6 mm	18.2 mm	0.236 in	0.717 in	0.15 ÁF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	15 mm	0.591 in	Through Hole	11.2 mm	0.441 in	-40 °C	105 ░C	PC Pins	5 %
Panasonic Industrial Automation Sales ECW-FA2J334JB	0.335 in	0.717 in			0.33 µF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	7.5 mm	0.295 in	Through Hole	18.6 mm	0.732 in	-40 °C	105 ░C	PC Pins	5 %			8.5 mm	18.2 mm
Panasonic Industrial Automation Sales ECW-FA2J334J4	0.335 in	0.717 in			0.33 µF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	15 mm	0.591 in	Through Hole			-40 °C	105 ░C	PC Pins	5 %			8.5 mm	18.2 mm
Panasonic Industrial Automation Sales ECW-FA2J564J4	10.9 mm	18.2 mm	0.429 in	0.717 in	0.56 µF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	15 mm	0.591 in	Through Hole			-40 °C	105 ░C	PC Pins	5 %					0.63 in	16 mm
Panasonic Industrial Automation Sales ECW-FA2J274J4	0.307 in 7.8 mm	0.717 in 18.2 mm			0.27 µF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	15 mm	0.591 in	Through Hole			-40 °C	105 ░C	PC Pins	5 %					0.508 in	12.9 mm
Panasonic Industrial Automation Sales ECW-FA2J154JB	6 mm	18.2 mm	0.236 in	0.717 in	0.15 ÁF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	7.5 mm	0.295 in	Through Hole	16.2 mm	0.638 in	-40 °C	105 ░C	PC Pins	5 %
Panasonic Industrial Automation Sales ECW-FA2J824J	10.1 mm	26 mm	0.398 in	1.024 in	0.82 µF	Metallized Polypropylene (PP)	High Frequency Switching	Radial	22.5 mm	0.886 in	Through Hole			-40 °C	105 ░C	PC Pins	5 %					0.602 in	15.3 mm	141 V
