VLM40E Series
Manufacturer: ERP Power, LLC
Beta
⌘K
LED DRVR CV AC/DC 48V 830MA
| Part | Mounting Type | Voltage - Input (Min) [Min] | Type | Voltage - Input (Max) [Max] | Number of Outputs | Efficiency | Power (Watts) | Ratings | Voltage - Output | Current - Output (Max) [Max] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Approval Agency | Topology | Termination Style | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ERP Power, LLC | Chassis Mount | 220 VAC | Constant Voltage | 240 VAC | 1 | 93 % | 40 W | IP20 | 48 V | 830 mA | 19.8 mm | 183.2 mm | 0.78 in | 7.21 in | 21 mm | 0.83 " | CB CE cULus FCC | AC DC Converter | Terminal Block | 194 °F |
ERP Power, LLC | Chassis Mount | 220 VAC | Constant Voltage | 240 VAC | 1 | 93 % | 40 W | IP20 | 12 V | 3.33 A | 19.8 mm | 183.2 mm | 0.78 in | 7.21 in | 21 mm | 0.83 " | CB CE cULus FCC | AC DC Converter | Terminal Block | 194 °F |
ERP Power, LLC | Chassis Mount | 220 VAC | Constant Voltage | 240 VAC | 1 | 93 % | 40 W | IP20 | 24 V | 1.67 A | 19.8 mm | 183.2 mm | 0.78 in | 7.21 in | 21 mm | 0.83 " | CB CE cULus FCC | AC DC Converter | Terminal Block | 194 °F |
