ATS-544 Series

Manufacturer: Advanced Thermal Solutions Inc.

Catalog

HEATSINK 42.5X42.5X24.5MM NO TIM

Part	Type	Package Cooled	Material	Length	Length	Attachment Method	Thermal Resistance @ Forced Air Flow	Fin Height	Fin Height	Shape	Material Finish	Length [x]	Length [x]	Width	Width	Fin Height [custom]	Fin Height [custom]	Width [y]	Width [y]
Advanced Thermal Solutions Inc. ATS-54425W-C0-R0	Top Mount	BGA	Aluminum	42.5 mm	1.673 in	Thermal Tape Adhesive	2.2 °C/W	24.5 mm	0.965 in	Fins Square	Black Anodized
Advanced Thermal Solutions Inc. ATS-54450W-C0-R0	Top Mount	BGA	Aluminum			Thermal Tape Adhesive	2.1 °C/W	24.5 mm	0.965 in	Fins Square	Black Anodized	1.772 in	45 mm	1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-54425R-C0-R0	Top Mount	BGA	Aluminum	42.5 mm	1.673 in	Thermal Tape Adhesive	3 °C/W	19.5 mm	0.768 in	Fins Square	Black Anodized
Advanced Thermal Solutions Inc. ATS-54425K-C0-R0	Top Mount	BGA	Aluminum	42.5 mm	1.673 in	Thermal Tape Adhesive	4.3 °C/W			Fins Square	Black Anodized					0.571 in	14.5 mm
Advanced Thermal Solutions Inc. ATS-54400D-C0-R0	Top Mount	BGA	Aluminum			Thermal Tape Adhesive	9.1 °C/W	9.5 mm	0.374 in	Fins Square	Black Anodized							1.575 in	40 mm
Advanced Thermal Solutions Inc. ATS-54400K-C0-R0	Top Mount	BGA	Aluminum			Thermal Tape Adhesive	4.6 °C/W			Fins Square	Black Anodized					0.571 in	14.5 mm	1.575 in	40 mm
Advanced Thermal Solutions Inc. ATS-54450R-C0-R0	Top Mount	BGA	Aluminum			Thermal Tape Adhesive	2.8 °C/W	19.5 mm	0.768 in	Fins Square	Black Anodized	1.772 in	45 mm	1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-54450D-C0-R0	Top Mount	BGA	Aluminum			Thermal Tape Adhesive	8.4 °C/W	9.5 mm	0.374 in	Fins Square	Black Anodized	1.772 in	45 mm	1.772 in	45 mm
Advanced Thermal Solutions Inc. ATS-54425D-C0-R0	Top Mount	BGA	Aluminum	42.5 mm	1.673 in	Thermal Tape Adhesive	8.4 °C/W	9.5 mm	0.374 in	Fins Square	Black Anodized
