29056 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE SPDT 11A 24V
| Part | Coil Resistance | Features | Termination Style | Switching Voltage | Release Time | Coil Type | Operating Temperature [Max] | Operating Temperature [Min] | Approval Agency | Mounting Type | Contact Material | Coil Current | Relay Type | Contact Form | Coil Voltage | Contact Rating (Current) | Operate Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 1.33 kOhms | Diode Lighted Indicator Socket Included | Screw Terminal | 250 VAC 250 VDC | 10 ms | Non Latching | 60 °C | -40 C | CSA | DIN Rail | Silver Nickel (AgNi) | 18 mA | General Purpose | SPDT (1 Form C) | 24 VDC | 11 A | 9 ms |
 Phoenix Contact | 51.11 kOhms | Lighted Indicator Socket Included Varistor | Screw Terminal | 250 VAC 250 VDC | 20 ms | Non Latching | 45 °C | -40 C | CSA | DIN Rail | Silver Nickel (AgNi) | 4.5 mA | General Purpose | DPDT (2 Form C) | 230 VAC | 5 A | 12 ms |
 Phoenix Contact | 1.33 kOhms | Diode Lighted Indicator Socket Included | Screw Terminal | 250 VAC 250 VDC | 10 ms | Non Latching | 60 °C | -40 C | CSA | DIN Rail | Silver Nickel (AgNi) | 18 mA | General Purpose | SPDT (1 Form C) | 24 VDC | 8 A | 9 ms |
Phoenix Contact | 51.11 kOhms | Lighted Indicator Socket Included Varistor | Screw Terminal | 250 VAC 250 VDC | 20 ms | Non Latching | 50 °C | -40 C | CSA | DIN Rail | Silver Nickel (AgNi) | 4.5 mA | General Purpose | SPDT (1 Form C) | 230 VAC | 8.5 A | 12 ms |
