60AR18 Series
Manufacturer: Grayhill Inc.
Beta
⌘K
SWITCH JOYSTICK FLATTED 10MA 5V
| Part | Operating Force | Mechanical Life | Current Rating (Amps) | Voltage Rating - DC | Actuator Type | Panel Cutout Dimensions [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Ingress Protection | Output | Switch Function | Mounting Type | Type | Type | Termination Style | Voltage - Supply |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 4-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
 Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 8-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 4-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 8-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 8-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
 Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 8-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 8-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 8-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
Grayhill Inc. | 1500 gf | 500000 Cycles | 10 mA | 5 V | Flatted (6.35mm Dia) | 17.25 mm | 85 °C | -40 C | IP67 - Dust Tight Waterproof | Digital (Mechanical Switch Pulse) | 360° Rotational 8-Way Directional Center Select | Panel Mount | 3 Shelves | Joystick | Cable with Connector | 5 VDC |
