VX78012 Series
Manufacturer: CUI Inc.
Beta
⌘K
DC DC CONVERTER 12V 12W
| Part | Mounting Type | Applications | Power (Watts) | Voltage - Input (Min) [Min] | Type | Current - Output (Max) [Max] | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Input (Max) [Max] | Voltage - Output 1 | Approval Agency | Standard Number | Efficiency | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Number of Outputs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | Through Hole | ITE (Commercial) | 12 W | 16 V | Linear Regulator Replacement | 1 A | 3-SIP Module | -40 °C | 85 °C | 36 V | 12 V | CB Scheme EN IEC UL | 55024 55032 Class A 60950-1 | 96 % | 9 mm | 0.69 in | 0.35 in | 0.45 " | 11.5 mm | 17.5 mm | 1 |
