155210 Series

Flamar Distribution Box Cable, PVC Jacket, Unshielded, 7 Circuits, 3x(0.75mm²) with Green-Yellow Ground + 4x(0.34mm²) / 3x(19 AWG) with Green-Yellow Ground + 4x(22 AWG), 7.80mm (.307") Diameter, 300.0m (984.25') Length, Gray

Manufacturer: Molex

Catalog

Flamar Distribution Box Cable, PVC Jacket, Unshielded, 7 Circuits, 3x(0.75mm²) with Green-Yellow Ground + 4x(0.34mm²) / 3x(19 AWG) with Green-Yellow Ground + 4x(22 AWG), 7.80mm (.307") Diameter, 300.0m (984.25') Length, Gray

Catalog

Flamar Distribution Box Cable, PVC Jacket, Unshielded, 7 Circuits, 3x(0.75mm²) with Green-Yellow Ground + 4x(0.34mm²) / 3x(19 AWG) with Green-Yellow Ground + 4x(22 AWG), 7.80mm (.307") Diameter, 300.0m (984.25') Length, Gray

...

Part	Voltage	Jacket (Insulation) Material	Number of Conductors	Cable Type	Ratings	Operating Temperature [Min]	Operating Temperature [Max]	Jacket Color	Wire Gauge	Jacket (Insulation) Thickness [x]	Jacket (Insulation) Thickness [x]	Conductor Material	Conductor Insulation	Conductor Insulation	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Length [x]	Length [x]	Number of Conductors [custom]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Strand [diameter]	Length	Length	Jacket (Insulation) Thickness
Molex 1552100316	300 VDC	Poly-Vinyl Chloride (PVC)	17	Multi-Conductor	UL Style 2464	5 °C	80 °C	Gray	14.5 AWG	0.5 mm	0.0197 in	Copper Bare	TPE	Thermoplastic Elastomer	18.49 mm	0.728 "	133	0.0059 in	328.1 ft	100 m
Molex 1552100270	300 VDC	Poly-Vinyl Chloride (PVC)		Multi-Conductor	UL Style 2464	5 °C	80 °C	Gray	16 AWG			Copper Bare	TPE	Thermoplastic Elastomer		17.7 mm	81		1640.4 ft	500 m	25	0.45 mm	0.0177 in	0.697 in	0.0059 in
Molex 1552100072	300 VDC	Poly-Vinyl Chloride (PVC)	4	Multi-Conductor	UL Style 2464	5 °C	80 °C	Yellow	22 AWG			Copper Bare	TPE	Thermoplastic Elastomer		5.11 mm			4921 ft	1500 m		0.25 mm	0.0098 "	0.201 in		42	0.0039 "
Molex 1552100294	300 VDC	Poly-Vinyl Chloride (PVC)	5	Multi-Conductor	UL Style 2464	5 °C	80 °C	Gray	14.5 AWG	0.5 mm	0.0197 in	Copper Bare	TPE	Thermoplastic Elastomer		11.3 mm	133	0.0059 in						0.445 in				3281 '	1000 m
Molex 1552100115	300 VDC	Poly-Vinyl Chloride (PVC)	4	Multi-Conductor	UL Style 2464	5 °C	80 °C	Black	21 AWG			Copper Bare	TPE	Thermoplastic Elastomer		5.89 mm	28	0.0059 in	984.3 ft	300 m		0.0114 "		0.232 in						0.29 mm
Molex 1552100262	300 VDC	Poly-Vinyl Chloride (PVC)	17	Multi-Conductor	UL Style 2464	5 °C	80 °C	Gray	16 AWG			Copper Bare	TPE	Thermoplastic Elastomer		14.71 mm	81		328.1 ft	100 m		0.45 mm	0.0177 in	0.579 in	0.0059 in
Molex 1552100113	300 VDC	Poly-Vinyl Chloride (PVC)	3	Multi-Conductor	UL Style 2464	5 °C	80 °C	Orange	21 AWG			Copper Bare	TPE	Thermoplastic Elastomer		5.59 mm	28	0.0059 in	1640.4 ft	500 m		0.0114 "		0.22 in						0.29 mm
Molex 1552100305	300 VDC	Poly-Vinyl Chloride (PVC)	11	Multi-Conductor	UL Style 2464	5 °C	80 °C	Gray	14.5 AWG	0.5 mm	0.0197 in	Copper Bare	TPE	Thermoplastic Elastomer		15.7 mm	133	0.0059 in						0.618 in				820.2 '	250 m
Molex 1552109013	300 VDC	Poly-Vinyl Chloride (PVC)	11	Multi-Conductor	UL Style 2464	5 °C	80 °C	Black	19 AWG 22 AWG			Copper Bare	TPE	Thermoplastic Elastomer		8.51 mm	42							0.335 in			0.0039 " 0.0059 in	656.2 ft	200 m
Molex 1552100197	300 VDC	Poly-Vinyl Chloride (PVC)	12	Multi-Conductor	UL Style 2464	5 °C	80 °C	Gray	18 AWG	0.381 mm	0.015 in	Copper Bare	TPE	Thermoplastic Elastomer		11.51 mm	52	0.0059 in	1640.4 ft	500 m				0.453 in
