173-E09 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, DB9, STANDARD, RECEPTACLE, 173-E M SERIES, 9 CONTACTS, DE, SOLDER
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Connector Type | Contact Finish Thickness | Mounting Type | Current Rating (Amps) | Flange Feature | Flange Feature | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Type | Material Flammability Rating | Shell Material, Finish | Number of Positions | Number of Rows [custom] | Contact Finish | Backset Spacing | Backset Spacing | Connector Style | Features | Termination | Shell Material, Finish [custom] | Shell Material, Finish [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper | Receptacle Female Sockets | Flash | Right Angle Through Hole | 5 A | Housing/Shell | 4-40 | 1 | DE E | Signal | UL94 V-0 | Nickel Plated Steel | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Board Lock Mounting Brackets | Solder | ||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper | Receptacle Female Sockets | Flash | Right Angle Through Hole | 5 A | 4-40 Mating Side Female Screwlock | 1 | DE E | Signal | UL94 V-0 | Nickel Plated Steel | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Mounting Brackets | Solder | |||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | -55 C | 125 °C | White | Copper | Receptacle Female Sockets | Flash | Right Angle Through Hole | 5 A | Housing/Shell (Unthreaded) | 1 | DE E | Signal | UL94 V-0 | Nickel Plated Steel | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Solder | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | White | Plug Male Pins | Flash | Panel Mount Right Angle Through Hole | 5 A | Housing/Shell (Unthreaded) | 1 | DE E | Signal | UL94 V-0 | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Solder | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | White | Brass | Plug Male Pins | Flash | Panel Mount Right Angle Through Hole | 5 A | 4-40 Mating Side Female Screwlock | 1 | DE E | Signal | UL94 V-0 | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Grounding Indents Mounting Brackets | Solder | ||||
 NorComp Inc. | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | White | Receptacle Female Sockets | Flash | Panel Mount Right Angle Through Hole | 5 A | 4-40 Mating Side Female Screwlock | 1 | DE E | Signal | UL94 V-0 | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Mounting Brackets | Solder | |||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | White | Receptacle Female Sockets | Flash | Panel Mount Right Angle Through Hole | 5 A | Housing/Shell (Unthreaded) | 1 | DE E | Signal | UL94 V-0 | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Solder | Steel | Yellow Chromate Plated | ||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | White | Receptacle Female Sockets | Flash | Panel Mount Right Angle Through Hole | 5 A | 4-40 Mating Side Female Screwlock | 1 | DE E | Signal | UL94 V-0 | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Mounting Brackets | Solder | Steel | Yellow Chromate Plated | |||
NorComp Inc. | Polybutylene Terephthalate (PBT) | -50 °C | 100 °C | White | Brass | Plug Male Pins | Flash | Panel Mount Right Angle Through Hole | 5 A | Housing/Shell (Unthreaded) | 1 | DE E | Signal | UL94 V-0 | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Grounding Indents | Solder | ||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | -50 °C | 100 °C | White | Brass | Plug Male Pins | Flash | Panel Mount Right Angle Through Hole | 5 A | Mating Side Standard Screws (4-40) | 1 | DE E | Signal | UL94 V-0 | 9 | 2 | Gold | 7.2 mm | 0.283 in | D-Sub | Mounting Brackets | Solder | Steel | Yellow Chromate Plated |
