M83513/19 Series
Manufacturer: Cinch Connectivity Solutions
Beta
⌘K
CONN MICRO-D RCPT 15POS R/A SLDR
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Dielectric Material | Shell Material, Finish | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Material Flammability Rating | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Termination | Number of Positions | Backset Spacing | Backset Spacing | Number of Rows [custom] | Flange Feature | Contact Finish | Connector Type | Current Rating (Amps) | Contact Type | Connector Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cinch Connectivity Solutions | -55 C | 125 °C | Copper Alloy | Polyester Glass Filled | Aluminum Alloy Electroless Nickel Plated | 0.05 | 0.05 | UL94 V-0 | Right Angle Through Hole | 50 µin | 1.27 µm | Solder | 15 | 0.275 in | 6.99 mm | 2 | Mating Side Female Screwlock (2-56) | Gold | Receptacle Female Sockets | 3 A | Signal | D-Type Micro-D |
Cinch Connectivity Solutions | -55 C | 125 °C | Copper Alloy | Polyester Glass Filled | Aluminum Alloy Yellow Chromate Plated Cadmium | 0.05 | 0.05 | UL94 V-0 | Right Angle Through Hole | 50 µin | 1.27 µm | Solder | 9 | 0.275 in | 6.99 mm | 2 | Mating Side Female Screwlock (2-56) | Gold | Receptacle Female Sockets | 3 A | Signal | D-Type Micro-D |
 Cinch Connectivity Solutions | -55 C | 125 °C | Copper Alloy | Polyester Glass Filled | Aluminum Alloy Yellow Chromate Plated Cadmium | 0.05 | 0.05 | UL94 V-0 | Right Angle Through Hole | 50 µin | 1.27 µm | Solder | 21 | 0.275 in | 6.99 mm | 2 | Mating Side Female Screwlock (2-56) | Gold | Receptacle Female Sockets | 3 A | Signal | D-Type Micro-D |
Cinch Connectivity Solutions | -55 C | 125 °C | Copper Alloy | Polyester Glass Filled | Aluminum Alloy Yellow Chromate Plated Cadmium | 0.05 | 0.05 | UL94 V-0 | Right Angle Through Hole | 50 µin | 1.27 µm | Solder | 15 | 0.275 in | 6.99 mm | 2 | Mating Side Female Screwlock (2-56) | Gold | Receptacle Female Sockets | 3 A | Signal | D-Type Micro-D |
