G9SX-NS Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
CONTROL SAFETY INTERLOCK 24V
| Part | Features | Features [Max] | Features [Min] | Voltage - Supply | Safety Outputs and Type | Mounting Type | Number of Inputs and Type [custom] | Number of Inputs and Type [custom] | Controller Type | Auxiliary Outputs and Type | Operating Temperature [Max] [custom] | Operating Temperature [Min] [custom] | Termination Style | Approval Agency | Safety Category | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | Logical AND I/O | 3 sec | 0 sec | 24 VDC | Solid State (4) | DIN Rail | Digital | 2 | Magnetic Interlock | Solid State (2) | 55 °C | -10 °C | Screw Terminal | CE CSA cULus SUD TUV UL | Category 3 PLd | 200.03 g | 0.441 lb |
Omron Electronics Inc-EMC Div | Logical AND I/O | 3 sec | 0 sec | 24 VDC | Solid State (4) | DIN Rail | Digital | 2 | Magnetic Interlock | Solid State (2) | 55 °C | -10 °C | Spring Terminal | CE CSA cULus SUD TUV UL | Category 3 PLd | 200.03 g | 0.441 lb |
 Omron Electronics Inc-EMC Div | Logical AND I/O | 24 VDC | Solid State (2) | DIN Rail | Digital | 2 | Magnetic Interlock | Solid State (2) | 55 °C | -10 °C | Spring Terminal | CE CSA cULus SUD TUV UL | Category 3 PLd | 125.19 g | 0.276 lb | ||
 Omron Electronics Inc-EMC Div | Logical AND I/O | 24 VDC | Solid State (2) | DIN Rail | Digital | 2 | Magnetic Interlock | Solid State (2) | 55 °C | -10 °C | Screw Terminal | CE CSA cULus SUD TUV UL | Category 3 PLd | 125.19 g | 0.276 lb |
