24_SMC-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
24_SMC-50-2-110/111_NE
| Part | Mating Cycles | Body Finish | Operating Temperature [Min] | Operating Temperature [Max] | Dielectric Material | Center Contact Plating | Body Material | Contact Termination | Impedance | Number of Ports | Connector Style | Mounting Feature | Mounting Type | Fastening Type | Shield Termination | Housing Color | Connector Type | Cable Group | Frequency - Max [Max] | Center Contact Material | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | 500 | Gold | -65 ░C | 165 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | Crimp | 50 Ohms | 1 | SMC | Bulkhead - Front Side Nut | Panel Mount | Threaded | Crimp | Gold | Female Socket Jack | 188 316 RG-174 | 10 GHz | Brass | |
 Huber+Suhner, Inc. | 500 | Gold | -65 ░C | 165 °C | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | Crimp | 50 Ohms | 1 | SMC | Bulkhead - Front Side Nut | Panel Mount | Threaded | Crimp | Gold | Female Socket Jack | RG-178 | 10 GHz | Brass | 196 |
