PZC20 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 20POS 2.54MM

Part	Style	Insulation Height	Insulation Height	Number of Positions Loaded	Termination	Number of Rows	Insulation Color	Connector Type	Contact Finish - Post	Contact Finish - Mating	Contact Material	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Mounting Type	Material Flammability Rating	Shrouding	Current Rating (Amps)	Fastening Type	Contact Type	Contact Shape	Insulation Material	Contact Length - Mating	Contact Length - Mating	Contact Length - Post	Contact Length - Post	Number of Positions	Overall Contact Length	Overall Contact Length	Overall Contact Length	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Rows [custom]	Insulation Height [z]	Insulation Height [z]	Contact Length - Post [custom]	Contact Length - Post [custom]
Sullins Connector Solutions PZC20SBCN	Board to Board Cable	3.56 mm	0.14 in	All	Solder	1	Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Right Angle Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.23 in	5.84 mm	8.13 mm	0.32 in	20
Sullins Connector Solutions PZC20SFEN	Board to Board Cable	2.54 mm	0.1 in	All	Solder	1	Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.318 in	8.08 mm	13.21 mm	0.52 in	20	23.83 mm	0.938 in
Sullins Connector Solutions PZC20DFCN	Board to Board Cable	2.54 mm	0.1 in	All	Solder		Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.318 in	8.08 mm	8.13 mm	0.32 in	40	18.75 mm		0.738 in	0.1 in	2.54 mm	2
Sullins Connector Solutions PZC20SBAN	Board to Board Cable	3.56 mm	0.14 in	All	Solder	1	Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Right Angle Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.23 in	5.84 mm	3.05 mm	0.12 in	20
Sullins Connector Solutions PZC20DBBN	Board to Board Cable			All	Solder		Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Right Angle Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.23 in	5.84 mm	5.84 mm	0.23 "	40				0.1 in	2.54 mm	2	6.1 mm	0.24 in
Sullins Connector Solutions PZC20DGAN	Board to Board Cable			All	Solder		Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Right Angle Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.318 in	8.08 mm	3.05 mm	0.12 in	40				0.1 in	2.54 mm	2	6.1 mm	0.24 in
Sullins Connector Solutions PZC20DACN	Board to Board Cable	2.54 mm	0.1 in	All	Solder		Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.23 in	5.84 mm	8.13 mm	0.32 in	40	16.51 mm	0.65 in		0.1 in	2.54 mm	2
Sullins Connector Solutions PZC20DFDN	Board to Board Cable	2.54 mm	0.1 in	All	Solder		Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.318 in	8.08 mm	10.67 mm	0.42 in	40	21.29 mm	0.838 in		0.1 in	2.54 mm	2
Sullins Connector Solutions PZC20DAFN	Board to Board Cable	2.54 mm	0.1 in	All	Solder		Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.23 in	5.84 mm			40	24.13 mm	0.95 in		0.1 in	2.54 mm	2			15.75 mm	0.62 "
Sullins Connector Solutions PZC20SACN	Board to Board Cable	2.54 mm	0.1 in	All	Solder	1	Black	Header	Tin	Gold	Copper Alloy	0.1 "	2.54 mm	2.54 µm	100 µin	0.25 µm	10 µin	Through Hole	UL94 V-0	Unshrouded	3 A	Push-Pull	Male Pin	Square	Polyester Thermoplastic	0.23 in	5.84 mm	8.13 mm	0.32 in	20	16.51 mm	0.65 in
